机器外形尺寸Dimension

980 * 1100 * 1780mm

运动行程（X*Y *Z/C）Travel Range

500 *650 *80/80mm

产品最大尺寸 Product Max .Size

200 *300/200 *300mm

运动控制方式 Motion Control Mode

微型工控机(IPC)

驱动方式Drive Mode

伺服马达/伺服丝杆 Servo r Motor/Ball Screw

机器轴数Number of Axis

6 Axes

激光功率范围Laser Power Range

0-300W

最大移动速度Travel Maximum

1000mm/s

电源最大功耗Max Power Consumption

185-265V/1500W

电源平均功耗Average Power Consumption

450W

重复定位精度Repeat Position Accuracy

±0 .01mm

锡球范围Diameter of Solder Ball

0.2-1.8mm

总重量Weight

700Kg

激光光源种类Laser Type

光纤 Fiber Laser

最小焊接间距Minimum Soldering Distance

0.2mm

氮气压力Nitrogen Pressure

3-12Bar

氮气流速Nitrogen Flow Rate

0.75L/min
